Spotboy Zoom 48V | 12.6W

Product Reference

Environment Indoor

Installation Track Mounted

Construction & Materials

Housing Die Cast Aluminium,Milled Aluminium

Primary Lens PMMA

Primary Reflector -

Secondary Reflector -

Body Finish White,Black

Diffuser -

Antiglare Baffle -

Thermal Management

Heat Sink Material Die cast Aluminium

Cooling Technique Passive Cooling

Optical System

Beam Direction Adjustable

Tilt Yes

Swivel Yes

Electrical System

Driven with Constant Voltage Driver

Input Voltage/Hz 48V

Control Gear Included

Mounting Remote

LED Power Watts 12.5W

System Power Watts -

Operating Voltage Vin 48V

Power Factor p.f. -

LED Technology

Binning 3 Step MacAdam

LED Life Time @ L70/B10 >50000 hours

Colour Rendering (CRI) CRI80,CRI90

Led Type COB

LED Fitted Cree COB LED 33V-36Vdc/350mA

Controls

Standard Switchable On/Off

Optional DDIM,BTTM,CASAMBI,Non Dimmable

Ordering Details

Code Example:

Name Watt CCT CRI Angle Finish Control
Spotboy Zoom 48V 12.6W WW27K CRI80 20°- 43° SWH On/Off

Select one from each column with highlighted values to create the ordering code

NAME WATT LUMEN EFFICACY CCT CRI ANGLE FINISH CONTROL
Spotboy Zoom 48V 12.6W 1250 100 2700K WW27K CRI80 20°- 43° White SWH Non Dimmable On/Off
1288 103 3000K WW30K CRI90 Black SBL Dali Dimmable DDIM
1350 108 4000K NW40K Bluetooth Dimmable BTTM
1375 110 5700K CW57K Casambi CBTM
2700K-5700K TW
Warm to Dim W2D
Spotboy Zoom 48V 12.6W WW27K CRI80 20°- 43° SWH On/Off
