Sigma 60 WW 2-way | 2x8W

Product Reference

Environment Indoor

Installation Ceiling Recess

Construction & Materials

Housing Aluminium

Primary Lens -

Primary Reflector PC metallised

Secondary Reflector Anodised

Body Finish White,Black,Custom

Diffuser -

Antiglare Baffle -

Thermal Management

Heat Sink Material Extruded Aluminium

Cooling Technique Passive Cooling

Optical System

Beam Direction Fixed Asymmetric

Tilt -

Swivel -

Electrical System

Driven with Constant Current Driver

Input Voltage/Hz 220V- 240V/50-60Hz

Control Gear Included

Mounting Integral

LED Power Watts 7.0

System Power Watts 8.0

Operating Voltage Vin 220-240Vac

Power Factor p.f. >0.95

LED Technology

Binning 3 Step MacAdam

LED Life Time @ L70/B10 >50000 hours

Colour Rendering (CRI) CRI80

Led Type COB

LED Fitted Cree COB LED 33V-36Vdc/180mA

Controls

Standard Switchable On/Off

Optional DDIM

Ordering Details

Code Example:

Name Watt CCT CRI Angle Finish Control
Sigma 60 WW 2-way 2x8W 2700K CRI80 Asymmetric SWH On/Off

Select one from each column with highlighted values to create the ordering code

NAME WATT LUMEN EFFICACY CCT CRI ANGLE FINISH CONTROL
Sigma 60 WW 2-way 2x8W 2x600 75 2700K 2700K CRI80 Asymmetric White SWH Non Dimmable On/Off
2x616 77 3000K 3000K Black SBL Dali Dimmable DDIM
2x648 81 4000K 4000K Custom CSM
2x664 83 5700K 5700K
Sigma 60 WW 2-way 2x8W 2700K CRI80 Asymmetric SWH On/Off
