Product Reference
Environment Indoor
Installation Ceiling Recess
Construction & Materials
Housing Aluminium
Primary Lens -
Primary Reflector PC metallised
Secondary Reflector Anodised
Body Finish White,Black,Custom
Diffuser -
Antiglare Baffle -
Thermal Management
Heat Sink Material Extruded Aluminium
Cooling Technique Passive Cooling
Optical System
Beam Direction Fixed Asymmetric
Tilt -
Swivel -
Electrical System
Driven with Constant Current Driver
Input Voltage/Hz 220V- 240V/50-60Hz
Control Gear Included
Mounting Integral
LED Power Watts 10.4W
System Power Watts 12.0W
Operating Voltage Vin 220-240Vac
Power Factor p.f. >0.95
LED Technology
Binning 3 Step MacAdam
LED Life Time @ L80/B10 >50000 hours
Colour Rendering (CRI) CRI80
Led Type COB
LED Fitted Cree COB LED 33V-36Vdc/300mA
Controls
Standard Switchable On/Off
Optional DDIM
Light Distribution
Ordering Details
Code Example:
| Name | Watt | CCT | CRI | Angle | Finish | Control |
|---|---|---|---|---|---|---|
| Sigma 60 WW 2-way | 2x12W | WW27K | CRI80 | Asymmetric | SWH | On/Off |
Select one from each column with highlighted values to create the ordering code
| NAME | WATT | LUMEN | EFFICACY | CCT | CRI | ANGLE | FINISH | CONTROL | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Sigma 60 WW 2-way | 2x12W | 2x840 | 70 | 2700K | WW27K | CRI80 | Asymmetric | White | SWH | Non Dimmable | On/Off |
| 2x864 | 72 | 3000K | WW30K | Black | SBL | Dali Dimmable | DDIM | ||||
| 2x888 | 74 | 4000K | NW40K | Custom | CSM | ||||||
| 2x912 | 76 | 5700K | CW57K | ||||||||
| Sigma 60 WW 2-way | 2x12W | WW27K | CRI80 | Asymmetric | SWH | On/Off | |||||
