Product Reference
Environment Indoor
Installation Ceiling Recess
Construction & Materials
Housing Aluminium
Primary Lens PMMA
Primary Reflector PC metallised
Secondary Reflector Anodised
Body Finish White,Black
Diffuser -
Antiglare Baffle -
Thermal Management
Heat Sink Material Die cast Aluminium
Cooling Technique Passive Cooling
Optical System
Beam Direction Fixed
Tilt No
Swivel No
Electrical System
Driven with Constant Current Driver
Input Voltage/Hz 220V- 240V/50-60Hz
Control Gear Included
Mounting Integral
LED Power Watts 20.6W
System Power Watts 23.7W
Operating Voltage Vin 220-240Vac
Power Factor p.f. >0.95
LED Technology
Binning 3 Step MacAdam
LED Life Time @ L80/B10 >50000 hours
Colour Rendering (CRI) CRI80,CRI90
Led Type COB
LED Fitted Cree COB LED 33V-36Vdc/600mA
Controls
Standard Switchable On/Off
Optional PDIM,DDIM,BTTM
Light Distribution
Ordering Details
Code Example:
| Name | Watt | CCT | CRI | Angle | Finish | Control |
|---|---|---|---|---|---|---|
| Sigma 105 | 24W | WW27K | CRI80 | 27°(MD) | SWH | On/Off |
Select one from each column with highlighted values to create the ordering code
| NAME | WATT | LUMEN | EFFICACY | CCT | CRI | ANGLE | FINISH | CONTROL | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Sigma 105 | 24W | 2204 | 93 | 2700K | WW27K | CRI80 | 27°(MD) | White | SWH | Non Dimmable | On/Off |
| 2275 | 96 | 3000K | WW30K | CRI90 | 36°(WD) | Black | SBL | Phase Dimmable | PDIM | ||
| 2394 | 101 | 4000K | NW40K | 53°(VWD) | Dali Dimmable | DDIM | |||||
| 2441 | 103 | 5700K | CW57K | Bluetooth Dimmable | BTTM | ||||||
| Sigma 105 | 24W | WW27K | CRI80 | 27°(MD) | SWH | On/Off | |||||
