ProLed 55 | 5W

Product Reference

Environment Indoor

Installation Ceiling Recess

Construction & Materials

Housing Die Cast Aluminium

Primary Lens PMMA

Primary Reflector -

Secondary Reflector Anodised

Body Finish White,Black

Diffuser -

Antiglare Baffle -

Thermal Management

Heat Sink Material Die cast Aluminium

Cooling Technique Passive Cooling

Optical System

Beam Direction Fixed

Tilt Yes

Swivel No

Electrical System

Driven with Constant Current Driver

Input Voltage/Hz 220V- 240V/50-60Hz

Control Gear Included

Mounting Remote

LED Power Watts 4.0W

System Power Watts 4.6W

Operating Voltage Vin 220-240 Vac

Power Factor p.f. > 0.5

LED Technology

Binning 3 Step MacAdam

LED Life Time @ L70/B10 >50000 hours

Colour Rendering (CRI) CRI80,CRI90

Led Type COB

LED Fitted Cree COB LED 36Vdc/130mA


Standard Switchable On/Off

Optional PDIM,DDIM,CASAMBI,Non Dimmable

Ordering Details

Code Example:

Name Watt CCT CRI Angle Finish Control
ProLed 55 5W WW27K CRI80 29°(SS) SWH On/Off

Select one from each column with highlighted values to create the ordering code

ProLed 55 5W 299 65 2700K WW27K CRI80 29°(SS) White SWH Non Dimmable On/Off
308 67 3000K WW30K CRI90 36°(MD) Black SBL Phase Dimmable PDIM
322 70 4000K NW40K 46°(WD) Dali Dimmable DDIM
331 72 5700K CW57K 57°(VWD) Casambi CBTM
Warm to Dim W2D
ProLed 55 5W WW27K CRI80 29°(SS) SWH On/Off
