Luke 35 2Way | 2X8W

Product Reference

Environment Indoor

Installation Ceiling Recess

Construction & Materials

Housing Mild Steel

Primary Lens -

Primary Reflector PC metallised

Secondary Reflector -

Body Finish White,Black,Custom

Diffuser -

Antiglare Baffle -

Thermal Management

Heat Sink Material Die cast Aluminium

Cooling Technique Passive Cooling

Optical System

Beam Direction Adjustable

Tilt Yes

Swivel Yes

Electrical System

Driven with Constant Current Driver

Input Voltage/Hz 220V- 240V/50-60Hz

Control Gear Included

Mounting Remote

LED Power Watts 2x6.6W

System Power Watts 2x8.3W

Operating Voltage Vin 220-240 Vac

Power Factor p.f. > 0.95

LED Technology

Binning 3 Step MacAdam

LED Life Time @ L70/B10 >50000 hours

Colour Rendering (CRI) CRI80,CRI90

Led Type COB

LED Fitted CREE COB LED 36Vdc/180mA

Controls

Standard Switchable On/Off

Optional PDIM,DDIM,BTTM,CASAMBI,Non Dimmable

Download Data Sheet

Back to Luke family
Optional

Light Distribution

Ordering Details

Code Example:

Name Watt CCT CRI Angle Finish Control
Luke 35 2Way 2X8W WW27K CRI80 16°(SS) SWH On/Off

Select one from each column with highlighted values to create the ordering code

NAME WATT LUMEN EFFICACY CCT CRI ANGLE FINISH CONTROL
Luke 35 2Way 2X8W 2x581 70 2700K WW27K CRI80 16°(SS) White SWH Non Dimmable On/Off
2x614 74 3000K WW30K CRI90 22°(MD) Black SBL Phase Dimmable PDIM
2x647 78 4000K NW40K 33°(WD) Custom CSM Dali Dimmable DDIM
2x672 81 5700K CW57K Bluetooth Dimmable BTTM
2700K-5700K TW Casambi CBTM
Luke 35 2Way 2X8W WW27K CRI80 16°(SS) SWH On/Off
