Product Reference
Environment Outdoor
Installation Floor Surface,Wall Surface,Wall Surface
Construction & Materials
Housing Die Cast Aluminium
Primary Lens PMMA
Primary Reflector PC metallised
Secondary Reflector -
Body Finish Black,Grey
Diffuser -
Antiglare Baffle -
Thermal Management
Heat Sink Material Die cast Aluminium
Cooling Technique Passive Cooling
Optical System
Beam Direction Adjustable
Tilt Yes
Swivel No
Electrical System
Driven with Constant Current Driver
Input Voltage/Hz 220V- 240V/50-60Hz
Control Gear Included
Mounting Integral
LED Power Watts 3.4W
System Power Watts 4.3W
Operating Voltage Vin 220-240 Vac
Power Factor p.f. > 0.5
LED Technology
Binning 3 Step MacAdam
LED Life Time @ L80/B10 >50000 hours
Colour Rendering (CRI) CRI80,CRI90
Led Type COB
LED Fitted CREE COB LED 9Vdc/350mA
Controls
Standard Switchable On/Off
Optional Non Dimmable
.png)
Light Distribution
Ordering Details
Code Example:
| Name | Watt | CCT | CRI | Angle | Finish | Control |
|---|---|---|---|---|---|---|
| Croc | 5W | WW27K | CRI80 | 16°(SS) | SBL | On/Off |
Select one from each column with highlighted values to create the ordering code
| NAME | WATT | LUMEN | EFFICACY | CCT | CRI | ANGLE | FINISH | CONTROL | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Croc | 5W | 357 | 83 | 2700K | WW27K | CRI80 | 16°(SS) | Black | SBL | Non Dimmable | On/Off |
| 378 | 88 | 3000K | WW30K | CRI90 | 22°(MD) | Grey | GGT | ||||
| 400 | 93 | 4000K | NW40K | 32°(WD) | |||||||
| 413 | 96 | 5700K | CW57K | ||||||||
| Croc | 5W | WW27K | CRI80 | 16°(SS) | SBL | On/Off | |||||
