Product Reference
Environment Indoor
Installation Ceiling Recess
Construction & Materials
Housing Extruded and Sheet Aluminium
Primary Lens -
Primary Reflector White Optics
Secondary Reflector -
Body Finish White,Black,Custom
Diffuser Opal PC,Microprismatic
Antiglare Baffle -
Thermal Management
Heat Sink Material Aluminium
Cooling Technique Passive Cooling
Optical System
Beam Direction General Diffuse
Tilt No
Swivel No
Electrical System
Driven with Constant Current Driver
Input Voltage/Hz 220V- 240V/50-60Hz
Control Gear Included
Mounting Integral
LED Power Watts 67.2W
System Power Watts 78.1W
Operating Voltage Vin 220-240 Vac
Power Factor p.f. > 0.95
LED Technology
Binning 3 Step MacAdam
LED Life Time @ L80/B10 >50000 hours
Colour Rendering (CRI) CRI80,CRI90
Led Type SMD mid power
LED Fitted Osram/Samsung Mid power LED array 43V-48Vdc/1550mA
Controls
Standard Switchable On/Off
Optional DDIM,CASAMBI,Non Dimmable
Light Distribution
Ordering Details
Code Example:
| Name | Watt | CCT | CRI | Angle | Finish | Control |
|---|---|---|---|---|---|---|
| Circulo R 120 | 78W | CRI80 | 96° | SWH | On/Off |
Select one from each column with highlighted values to create the ordering code
| NAME | WATT | LUMEN | EFFICACY | CCT | CRI | ANGLE | FINISH | CONTROL | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Circulo R 120 | 78W | 8513 | 109 | CRI80 | 96° | White | SWH | Non Dimmable | On/Off | ||
| 8669 | 111 | CRI90 | Black | SBL | Dali Dimmable | DDIM | |||||
| 8903 | 114 | Custom | CSM | Casambi | CBTM | ||||||
| 9060 | 116 | ||||||||||
| Circulo R 120 | 78W | CRI80 | 96° | SWH | On/Off | ||||||
