ZuG MPD P 120 | 20W
Product Reference
Environment
Indoor
Installation
Ceiling Suspended
Housing
Extruded Aluminium
Primary Lens
-
Primary Reflector
Aluminium White Painted
Secondary Reflector
-
Body Finish
White,Black
Diffuser
Microprismatic
Antiglare Baffle
Black,White,Custom
Heat Sink Material
Aluminium
Cooling Technique
Passive Cooling
Beam Direction
General Diffuse
Tilt
No
Swivel
No
Driven with
Constant Current Driver
Input Voltage/Hz
220V- 240V/50-60Hz
Control Gear
Included
Mounting
Integral
LED Power Watts
17.2W
System Power Watts
19.8W
Operating Voltage Vin
220-240 Vac
Power Factor p.f.
> 0.95
Binning
3 Step MacAdam
LED Life Time @ L70/B10
>50000 hours
Colour Rendering (CRI)
CRI80,CRI90
Led Type
SMD mid power
LED Fitted
Samsung Mid Power LED array 33V-36Vdc/500mA
Standard Switchable
On/Off
Optional
PDIM,DDIM,BTTM,CASAMBI,Non Dimmable
