Product Reference
Environment Indoor
Installation Ceiling Surface
Construction & Materials
Housing Aluminium Extrusion
Primary Lens PMMA
Primary Reflector -
Secondary Reflector PC Black Cover
Body Finish White,Black
Diffuser -
Antiglare Baffle Black,White,Custom
Thermal Management
Heat Sink Material Aluminium
Cooling Technique Passive Cooling
Optical System
Beam Direction Fixed
Tilt No
Swivel No
Electrical System
Driven with Constant Current Driver
Input Voltage/Hz 220V- 240V/50-60Hz
Control Gear Included
Mounting Integral
LED Power Watts 43.1W
System Power Watts 49.5W
Operating Voltage Vin 220-240 Vac
Power Factor p.f. > 0.95
LED Technology
Binning 3 Step MacAdam
LED Life Time @ L70/B10 >50000 hours
Colour Rendering (CRI) CRI80,CRI90
Led Type SMD high power
LED Fitted Cree 3030 LED array 39V-42Vdc/1050mA
Controls
Standard Switchable On/Off
Optional PDIM,DDIM,BTTM,CASAMBI,Non Dimmable
Light Distribution
Ordering Details
Code Example:
| Name | Watt | CCT | CRI | Angle | Finish | Control |
|---|---|---|---|---|---|---|
| ZuG Dark S 224 | 50W | WW27K | CRI80 | 28°(MD) | SWH | On/Off |
Select one from each column with highlighted values to create the ordering code
| NAME | WATT | LUMEN | EFFICACY | CCT | CRI | ANGLE | FINISH | CONTROL | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| ZuG Dark S 224 | 50W | 5495 | 111 | 2700K | WW27K | CRI80 | 28°(MD) | White | SWH | Non Dimmable | On/Off |
| 5643 | 114 | 3000K | WW30K | CRI90 | 66°(VWD) | Black | SBL | Phase Dimmable | PDIM | ||
| 5940 | 120 | 4000K | NW40K | Dali Dimmable | DDIM | ||||||
| 6039 | 122 | 5700K | CW57K | Bluetooth Dimmable | BTTM | ||||||
| Casambi | CBTM | ||||||||||
| ZuG Dark S 224 | 50W | WW27K | CRI80 | 28°(MD) | SWH | On/Off | |||||
