Product Reference
Environment Indoor
Installation Ceiling Recess
Construction & Materials
Housing Extruded and Sheet Aluminium
Primary Lens -
Primary Reflector White Optics
Secondary Reflector -
Body Finish White,Black,Custom
Diffuser Microprismatic
Antiglare Baffle -
Thermal Management
Heat Sink Material Aluminium
Cooling Technique Passive Cooling
Optical System
Beam Direction Fixed
Tilt -
Swivel -
Electrical System
Driven with Constant Current Driver
Input Voltage/Hz 220V- 240V/50-60Hz
Control Gear Included
Mounting Integral
LED Power Watts 24.0W
System Power Watts 27.6W
Operating Voltage Vin 220-240Vac
Power Factor p.f. >0.95
LED Technology
Binning 3 Step MacAdam
LED Life Time @ L80/B10 >50000 hours
Colour Rendering (CRI) CRI80,CRI90
Led Type SMD mid power
LED Fitted Osram/Samsung Mid power LED array 32V-36Vdc/700mA
Controls
Standard Switchable On/Off
Optional PDIM,DDIM,CASAMBI
Light Distribution
Ordering Details
Code Example:
| Name | Watt | CCT | CRI | Angle | Finish | Control |
|---|---|---|---|---|---|---|
| T Zee MPD 120 | 28W | WW27K | CRI80 | 79° | SWH |
Select one from each column with highlighted values to create the ordering code
| NAME | WATT | LUMEN | EFFICACY | CCT | CRI | ANGLE | FINISH | CONTROL | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| T Zee MPD 120 | 28W | 2732 | 99 | 2700K | WW27K | CRI80 | 79° | White | SWH | ||
| 2815 | 102 | 3000K | WW30K | CRI90 | Black | SBL | |||||
| 2953 | 107 | 4000K | NW40K | Custom | CSM | ||||||
| 3008 | 109 | 5700K | CW57K | ||||||||
| 2700K-5700K | TW | ||||||||||
| T Zee MPD 120 | 28W | WW27K | CRI80 | 79° | SWH | ||||||
