Product Reference
Environment Indoor
Installation Ceiling Suspended
Construction & Materials
Housing Extruded and Die Cast Aluminium
Primary Lens -
Primary Reflector -
Secondary Reflector -
Body Finish White,Black,Custom
Diffuser Microprismatic
Antiglare Baffle -
Thermal Management
Heat Sink Material Aluminium
Cooling Technique Passive Cooling
Optical System
Beam Direction Fixed
Tilt No
Swivel No
Electrical System
Driven with Constant Current Driver
Input Voltage/Hz 220V- 240V/50-60Hz
Control Gear Included
Mounting Remote
LED Power Watts 45.8W
System Power Watts 52.6W
Operating Voltage Vin 220-240 Vac
Power Factor p.f. > 0.95
LED Technology
Binning 3 Step MacAdam
LED Life Time @ L70/B10 >50000 hours
Colour Rendering (CRI) CRI80,CRI90
Led Type SMD mid power
LED Fitted -
Controls
Standard Switchable On/Off
Optional DDIM,CASAMBI,Non Dimmable
Light Distribution
Ordering Details
Code Example:
Name | Watt | CCT | CRI | Angle | Finish | Control |
---|---|---|---|---|---|---|
Slate D/I | 52W | WW27K | CRI80 | 91° | SWH | On/Off |
Select one from each column with highlighted values to create the ordering code
NAME | WATT | LUMEN | EFFICACY | CCT | CRI | ANGLE | FINISH | CONTROL | |||
---|---|---|---|---|---|---|---|---|---|---|---|
Slate D/I | 52W | 4734 | 2700K | WW27K | CRI80 | 91° | White | SWH | Non Dimmable | On/Off | |
4892 | 3000K | WW30K | CRI90 | Black | SBL | Dali Dimmable | DDIM | ||||
5155 | 4000K | NW40K | Custom | CSM | Casambi | CBTM | |||||
5260 | 5700K | CW57K | |||||||||
2700K-5700K | TW | ||||||||||
Slate D/I | 52W | WW27K | CRI80 | 91° | SWH | On/Off |
