Nexus 150 SDS P MPD 180 | 88W

Product Reference

Environment Indoor

Installation Ceiling Suspended

Construction & Materials

Housing Extruded Aluminium

Primary Lens PMMA

Primary Reflector PC metallised

Secondary Reflector PC Black Cover

Body Finish White,Black,Custom

Diffuser Microprismatic

Antiglare Baffle -

Thermal Management

Heat Sink Material Extruded Aluminium

Cooling Technique Passive Cooling

Optical System

Beam Direction Fixed

Tilt No

Swivel No

Electrical System

Driven with Constant Current Driver

Input Voltage/Hz 220V- 240V/50-60Hz

Control Gear Included

Mounting Integral

LED Power Watts 75.6W

System Power Watts 86.9W

Operating Voltage Vin 220V- 240V/50-60Hz

Power Factor p.f. > 0.95

LED Technology

Binning 3 Step MacAdam

LED Life Time @ L70/B10 >50000 hours

Colour Rendering (CRI) CRI80,CRI90

Led Type SMD mid power

LED Fitted Samsung Mid power LED array 32V-36Vdc/1500mA(S) + 700mA(D)

Controls

Standard Switchable On/Off

Optional DDIM,CASAMBI,Non Dimmable

Download Data Sheet

Back to Nexus 150 P SDS family
Optional

Light Distribution

Ordering Details

Code Example:

Name Watt CCT CRI Angle Finish Control
Nexus 150 SDS P MPD 180 88W WW27K CRI80 104°(S)+53°(D) SWH On/Off

Select one from each column with highlighted values to create the ordering code

NAME WATT LUMEN EFFICACY CCT CRI ANGLE FINISH CONTROL
Nexus 150 SDS P MPD 180 88W 7415 85 2700K WW27K CRI80 104°(S)+53°(D) White SWH Non Dimmable On/Off
7649 88 3000K WW30K CRI90 Black SBL Dali Dimmable DDIM
8057 93 4000K NW40K Custom CSM Casambi CBTM
8231 95 5700K CW57K
2700K-5700K TW
Nexus 150 SDS P MPD 180 88W WW27K CRI80 104°(S)+53°(D) SWH On/Off
