Product Reference
Environment Indoor
Installation Ceiling Recess
Construction & Materials
Housing Extruded Aluminium
Primary Lens -
Primary Reflector -
Secondary Reflector -
Body Finish White,Black,Custom
Diffuser Premium high-transmission opal
Antiglare Baffle -
Thermal Management
Heat Sink Material Aluminium
Cooling Technique Passive Cooling
Optical System
Beam Direction General Diffuse
Tilt No
Swivel No
Electrical System
Driven with Constant Current Driver
Input Voltage/Hz 220V- 240V/50-60Hz
Control Gear Included
Mounting Integral
LED Power Watts 47.7W
System Power Watts 54.8W
Operating Voltage Vin 220-240 Vac
Power Factor p.f. > 0.95
LED Technology
Binning 3 Step MacAdam
LED Life Time @ L80/B10 >50000 hours
Colour Rendering (CRI) CRI80,CRI90
Led Type SMD mid power
LED Fitted Osram/Samsung Mid power LED array 32V-38Vdc/1400mA
Controls
Standard Switchable On/Off
Optional DDIM,CASAMBI,Non Dimmable
Light Distribution
Ordering Details
Code Example:
| Name | Watt | CCT | CRI | Angle | Finish | Control |
|---|---|---|---|---|---|---|
| iNline R 240 | 60W | WW27K | CRI80 | 103° | SWH | On/Off |
Select one from each column with highlighted values to create the ordering code
| NAME | WATT | LUMEN | EFFICACY | CCT | CRI | ANGLE | FINISH | CONTROL | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| iNline R 240 | 60W | 5974 | 109 | WW27K | CRI80 | 103° | White | SWH | Non Dimmable | On/Off | |
| 6138 | 112 | CRI90 | Black | SBL | Dali Dimmable | DDIM | |||||
| 6522 | 119 | Custom | CSM | Casambi | CBTM | ||||||
| 6740 | 123 | ||||||||||
| iNline R 240 | 60W | WW27K | CRI80 | 103° | SWH | On/Off | |||||
