Product Reference
Environment Outdoor
Installation Ceiling Surface,Floor Surface,Wall Surface,Wall Surface
Construction & Materials
Housing Die Cast Aluminium
Primary Lens PMMA
Primary Reflector -
Secondary Reflector -
Body Finish Black,Grey
Diffuser -
Antiglare Baffle -
Thermal Management
Heat Sink Material Die cast Aluminium
Cooling Technique Passive Cooling
Optical System
Beam Direction Adjustable
Tilt Yes
Swivel No
Electrical System
Driven with Constant Current Driver
Input Voltage/Hz 220V- 240V/50-60Hz
Control Gear Included
Mounting Integral
LED Power Watts 18.1W
System Power Watts 20.8W
Operating Voltage Vin 220-240 Vac
Power Factor p.f. > 0.95
LED Technology
Binning 3 Step MacAdam
LED Life Time @ L80/B10 >50000 hours
Colour Rendering (CRI) CRI90
Led Type SMD high power
LED Fitted Osram LED 22V-27Vdc/700mA
Controls
Standard Switchable On/Off
Optional Non Dimmable
Light Distribution
Ordering Details
Code Example:
| Name | Watt | CCT | CRI | Angle | Finish | Control |
|---|---|---|---|---|---|---|
| GrassHopper | 22W | WW27K | CRI90 | 16°(SS) | SBL | On/Off |
Select one from each column with highlighted values to create the ordering code
| NAME | WATT | LUMEN | EFFICACY | CCT | CRI | ANGLE | FINISH | CONTROL | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| GrassHopper | 22W | 1747 | 84 | 2700K | WW27K | CRI90 | 16°(SS) | Black | SBL | Non Dimmable | On/Off |
| 1810 | 87 | 3000K | WW30K | 25°(MD) | Grey | GGT | |||||
| 1893 | 91 | 4000K | NW40K | 46°(WD) | |||||||
| 1934 | 93 | 5700K | CW57K | ||||||||
| GrassHopper | 22W | WW27K | CRI90 | 16°(SS) | SBL | On/Off | |||||
