Product Reference
Environment Indoor
Installation Ceiling Surface
Construction & Materials
Housing Die Cast Aluminium
Primary Lens PMMA
Primary Reflector -
Secondary Reflector Anodised
Body Finish White,Black,Custom
Diffuser -
Antiglare Baffle -
Thermal Management
Heat Sink Material Die cast Aluminium
Cooling Technique Passive Cooling
Optical System
Beam Direction Fixed
Tilt No
Swivel No
Electrical System
Driven with Constant Current Driver
Input Voltage/Hz 220V- 240V/50-60Hz
Control Gear Included
Mounting Integral
LED Power Watts 17.4W
System Power Watts 20.0W
Operating Voltage Vin 220-240 Vac
Power Factor p.f. > 0.95
LED Technology
Binning 3 Step MacAdam
LED Life Time @ L80/B10 >50000 hours
Colour Rendering (CRI) CRI80,CRI90
Led Type COB
LED Fitted CREE COB LED 36Vdc/500mA
Controls
Standard Switchable On/Off
Optional Non Dimmable
.png)
Light Distribution
Ordering Details
Code Example:
| Name | Watt | CCT | CRI | Angle | Finish | Control |
|---|---|---|---|---|---|---|
| Go Pro 50 S | 20W | WW27K | CRI80 | 24°(SS) | SWH | On/Off |
Select one from each column with highlighted values to create the ordering code
| NAME | WATT | LUMEN | EFFICACY | CCT | CRI | ANGLE | FINISH | CONTROL | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Go Pro 50 S | 20W | 1880 | 94 | 2700K | WW27K | CRI80 | 24°(SS) | White | SWH | Non Dimmable | On/Off |
| 1940 | 97 | 3000K | WW30K | CRI90 | 32°(MD) | Black | SBL | ||||
| 2040 | 102 | 4000K | NW40K | 36°(WD | Custom | CSM | |||||
| 2080 | 104 | 5700K | CW57K | )46°(VWD) | |||||||
| Go Pro 50 S | 20W | WW27K | CRI80 | 24°(SS) | SWH | On/Off | |||||
