Product Reference
Environment Indoor
Installation Ceiling Suspended
Construction & Materials
Housing Extruded and Die Cast Aluminium
Primary Lens -
Primary Reflector PC metallised
Secondary Reflector Black Raster – ABS
Body Finish White,Black,Custom
Diffuser -
Antiglare Baffle -
Thermal Management
Heat Sink Material Aluminium
Cooling Technique Passive Cooling
Optical System
Beam Direction -
Tilt No
Swivel No
Electrical System
Driven with Constant Current Driver
Input Voltage/Hz 220V- 240V/50-60Hz
Control Gear Included
Mounting Integral
LED Power Watts 43.3W
System Power Watts 49.8W
Operating Voltage Vin 220-240 Vac
Power Factor p.f. > 0.95
LED Technology
Binning 3 Step MacAdam
LED Life Time @ L70/B10 >50000 hours
Colour Rendering (CRI) CRI80,CRI90
Led Type SMD mid power
LED Fitted -
Controls
Standard Switchable On/Off
Optional DDIM,CASAMBI,Non Dimmable
Light Distribution
Ordering Details
Code Example:
| Name | Watt | CCT | CRI | Angle | Finish | Control |
|---|---|---|---|---|---|---|
| Dark Knight Flat D/I | 50W | WW27K | CRI80 | SWH | On/Off |
Select one from each column with highlighted values to create the ordering code
| NAME | WATT | LUMEN | EFFICACY | CCT | CRI | ANGLE | FINISH | CONTROL | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Dark Knight Flat D/I | 50W | 5229 | 105 | 2700K | WW27K | CRI80 | White | SWH | Non Dimmable | On/Off | |
| 5428 | 109 | 3000K | WW30K | CRI90 | Black | SBL | Dali Dimmable | DDIM | |||
| 5727 | 115 | 4000K | NW40K | Custom | CSM | Casambi | CBTM | ||||
| 5926 | 119 | 5700K | CW57K | ||||||||
| Dark Knight Flat D/I | 50W | WW27K | CRI80 | SWH | On/Off | ||||||
